| Model | Rated insulation Voltage（V） | Agreed fever Current（A） | Rated working current 400V AC3（A） | Control power（kw） | Number of contacts | Notes | ||||
| 230V | 400V | 415V | 440V | 690V | ||||||
| CJX2-0910 -0901 | 690 | 20 | 9 | 2.2 | 4 | 4 | 4 | 5.5 | 3P+NO 3P+NC | Installation method 1. Installation of two screws 2. Installation of 35mm guide rail |
| CJX2-1210 -1201 | 20 | 12 | 3 | 5.5 | 5.5 | 5.5 | 7.5 | 3P+NO 3P+NC | ||
| CJX2-1810 -1801 | 32 | 18 | 4 | 7.5 | 9 | 9 | 9 | 3P+NO 3P+NC | ||
| CJX2-2510 -2501 | 40 | 25 | 5.5 | 11 | 11 | 11 | 15 | 3P+NO 3P+NC | ||
| CJX2-3210 -3201 | 50 | 32 | 7.5 | 15 | 15 | 15 | 18.5 | 3P+NO 3P+NC | ||
| CJX2-4011 | 60 | 40 | 11 | 18.5 | 22 | 22 | 30 | Installation method 1. Installation of three screws 2. Installation of 75mm or 35mm guide rails | ||
| CJX2-5011 | 80 | 50 | 15 | 22 | 25 | 30 | 33 | |||
| CJX2-6511 | 80 | 65 | 18.5 | 30 | 37 | 37 | 37 | 3P+NO | ||
| CJX2-8011 | 125 | 80 | 22 | 37 | 45 | 45 | 45 | +NC | ||
| CJX2-9511 | 125 | 95 | 25 | 45 | 45 | 45 | 45 | |||
| Alternative Model Specifications | Rated Working Current(A) | Electrical Lifespan AC3(X104)次 | Mechanical Life (X105)次 | Volume(cm³) | Weight(kg) |
| CJ10-10 | 10 | 60 | 300 | 467 | 0.48 |
| CJX2-12 | 12 | 100 | 1000 | 247 | 0.32 |
| CJ10-20 | 20 | 60 | 300 | 1094 | 1 |
| CJX2-25 | 25 | 80 | 800 | 437 | 0.49 |
| CJ10-40 | 40 | 60 | 300 | 1682 | 1.8 |
| CJX2-40 | 40 | 80 | 800 | 1058 | 1.1 |
| CJ10-60 | 60 | 60 | 300 | 4169 | 4.45 |
| CJX2-65 | 65 | 60 | 800 | 1058 | 1.1 |
| CJ10-100 | 100 | 60 | 300 | 5809 | 6.27 |
| CJX2-95 | 95 | 60 | 800 | 1446 | 1.4 |
| Model | CJX2-09 | CJX2-12 | CJX2-18 | CJX2-25 | CJX2-32 | |||
| pull-in voltage 50/60Hz（A） | （0.85~1.1） Us | （0.85~1.1） Us | （0.85~1.1） Us | （0.85~1.1） Us | （0.85~1.1） Us | |||
| release voltage 50/60Hz（A） | （0.2~0.75） Us | （0.2~0.75） Us | （0.2~0.75） Us | （0.2~0.75） Us | （0.2~0.75） Us | |||
| coil power | 50Hz | close | （VA） | 70 | 70 | 110 | 110 | 110 |
| hold | （VA） | 8 | 8 | 11 | 11 | 11 | ||
| 60Hz | close | （VA） | 80 | 80 | 115 | 115 | 115 | |
| hold | （VA） | 8 | 8 | 11 | 11 | 11 | ||
| power dissipation | (W) | 1.8-2.7 | 1.8-2.7 | 3-4 | 3-4 | 3-4 | ||
| Model | CJX2-40 | CJX2-50 | CJX2-65 | CJX2-80 | CJX2-95 | |||
| pull-in voltage 50/60Hz（A） | （0.85~1.1） Us | （0.85~1.1） Us | （0.85~1.1） Us | （0.85~1.1） Us | （0.85~1.1） Us | |||
| release voltage 50/60Hz（A） | （0.2~0.75） Us | （0.2~0.75） Us | （0.2~0.75） Us | （0.2~0.75） Us | （0.2~0.75） Us | |||
| coil power | 50Hz | close | （VA） | 200 | 200 | 200 | 200 | 200 |
| hold | （VA） | 20 | 20 | 20 | 20 | 20 | ||
| 60Hz | close | （VA） | 200 | 200 | 200 | 200 | 200 | |
| hold | （VA） | 20 | 20 | 20 | 20 | 20 | ||
| power dissipation | (W) | 6-10 | 6-10 | 6-10 | 6-10 | 6-10 | ||
